Within the silicon carbide (SiC) industry chain, substrate suppliers hold significant leverage, primarily due to value distribution. SiC substrates account for 47% of the total value, followed by epitaxial layers at 23%, while device design and manufacturing constitute the remaining 30%. This inverted value chain stems from the high technological barriers inherent to substrate and epitaxial layer production. Three major challenges plague SiC substrate growth: stringent growth conditions, slow growth rates, and demanding crystallographic requirements. These complexities contribute to increased processing difficulty, ultimately resulting in low product yields and high costs. Furthermore, the epitaxial layer’s thickness and doping concentration are critical parameters directly impacting the final device performance.

The three primary methods used in monocrystalline silicon manufacturing are the Czochralski (CZ) method, the Kyropoulos method, and the Float Zone (FZ) method.

Epitaxial wafers have been used in the electronics industry for decades, but their importance has only increased as technology has advanced. In this article, we will explore what epitaxial wafers are and why they are such an essential component of modern electronics.

Etching is an essential process in semiconductor manufacturing. This process can be categorized into two types: dry etching and wet etching. Each technique has its own advantages and limitations, making it crucial to understand the differences between them. So, how do you choose the best etching method? What are the pros and cons of dry etching and wet etching?

Silicon carbide (SiC) is a material that possesses exceptional thermal, physical and chemical stability, exhibiting properties that go beyond those of conventional materials. Its thermal conductivity is an astonishing 84W/(m·K), which is not only higher than copper but also three times that of silicon. This demonstrates its enormous potential for use in thermal management applications.

AlN, as third-generation semiconductor material, is not only an important blue light and ultraviolet light material, but also an important packaging, dielectric isolation and insulation material for electronic devices and integrated circuits, especially suitable for high-temperature and high-power devices. In addition, AlN and GaN have a good thermal match and chemical compatibility, AlN used as GaN epitaxial substrate, can significantly reduce the defect density in GaN devices, improve device performance.
